• Physical anti-rodent method, green and environment-friendly
• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing key protection for fibres
• FRP tape armor providing good anti-rodent performance
• All-dielectric design, applicable to lightning-prone areas
• Applicable to aerial and duct installations with anti-rodent and anti-lightning requirements
Technical Characteristics
| Type GYFTY73 | Units |
Max. fibre count per tube |
Diameter (mm) |
Cable weight (kg/km) |
Tensile strength Long/short term (N) |
Crush Long/ short term （N/100mm） |
Bending radius Dynamic/ static (mm) |
|---|---|---|---|---|---|---|---|
| 2-72Xn | 6 | 12 | 13.2 | 132 | 1000/3000 | 300/1000 | 10D/20D |
Note:
1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.
2. For color arrangement of fibres and loose tubes, see the color sequence.
3. D is cable diameter.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available
