• Good mechanical and temperature performances
• Good crush resistance and flexibility
• Small size and light weight, supporting bulk data transmission
• Mainly applied to horizontal and vertical cabling at wireless base stations, applicable to FTTA(fibre to the antenna)
• Reducing the cable cost of FTTA, with the combined use of MPO connectors and splitters
Technical Characteristics
| Type |
Inner sheath diameter (mm) |
Cable diameter (mm) |
Cable weight (Kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static (mm) |
|---|---|---|---|---|---|---|
| GJYXFH-12Xn | 2.8 | 7.0 | 38.3 | 200/400 | 500/1000 | 20D/10D |
• Transport/storage temperature: -20℃ to +60℃
• Standard length: 2,000m; other lengths are also available.
