• Accurate process control ensuring good mechanical and temperature performances
• Unique flat shape providing excellent crush resistance, applicable to special wedge clamps for installation
• Two FRP strength members in parallel close to the tube, easy for stripping
• All-dielectric design, applicable to lightning-prone areas
• Uni-tube, small size and light weight, easy for installation
Technical Characteristics
| Type |
Tube diameter （mm） |
FRP diameter （mm） |
Cable size WxH （mm） |
Tensile strength Long/short term （N） |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static |
Cable weight Type （kg/km） |
|---|---|---|---|---|---|---|---|
| GYFXBY-02-24Xn | 3.0 | 1.6 | 8.1×4.6 | 400/1400 | 1000/5000 | 30H/15H | 35±5 |
• In the distribution segment of optical networks in rural areas, the cable can be used as drop cables for self-supporting aerial installation to connect branching points with access points for subscribers.
• Storage temperature: -40℃ to +70℃
• Standard length: 2,000m; other lengths are also available.
