• Figure-8 design, easy for self-supporting aerial installation, reducing installation cost
• Good mechanical and temperature performances
• Small size, light weight and soft, easy for installation
• Applicable to short distance self-supporting aerial installation
| Type |
Tube diameter （mm） |
Wire diameter （mm |
O.D. WxH （mm） |
Tensile strength Long/short term （N） |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static （mm） |
Cable weight （kg/km） |
|
| GYAXTC8Y-02-12Xn | 3.0 | 1.6 | 5.4×9.5 | 600/1500 | 300/1000 | 110/50 | 45±5 | |
| GYAXTC8Y-12-24Xn | 3.2 | 1.6 | 5.6×9.8 | 600/1500 | 300/1000 | 110/50 | 45±5 | |
| GYAXTC8-J-02-12Xn | 2.8 | 7×0.6 | 4.4×9.2 | 600/1500 | 300/1000 | 110/50 | 45±5 | |
| GYAXTC8Y-J-12-24Xn | 3.2 | 7×0.6 |
|
600/1500 | 300/1000 | 110/50 | 45±5 |
• In the distribution segment of optical networks in rural areas, the cable can be used as drop cables for the self-supporting aerial installation to connect branching points with access points for subscribers.
• Storage temperature: -40℃ to +70℃
• Standard length: 2,000m; other lengths are also available.
