• All-dry design, improving efficiency of construction and splicing
• Easy for branching of a single fibre
• Good mechanical and temperature performances
• Applicable to outdoor duct or aerial installations, and vertical installation
Technical Characteristics
| Type | Slot No. |
|
Buffer |
Fibre diameter （mm） |
Diameter of strength member （mm） |
Cable diameter (mm) |
Nominal thickness of sheath （mm） |
Cable weight （kg/km） |
||
|---|---|---|---|---|---|---|---|---|---|---|
| GTJGA-24Xn | 6 | 4 | PVC | 0.55 | 1.6 | 11.5 | 1.2 | 125 | ||
| GTJGA-48Xn | 6 | 8 | PVC | 0.55 | 1.6 | 12.8 | 1.2 | 140 |
• In the distribution segment of optical networks in rural areas, the cable can be used as drop cables for non self-supporting aerial installation to connect branching points with access points for subscribers.
• Storage temperature: -40℃ to +70℃
• Standard length: 2,000m; other lengths are also available.
