• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing key protection for fibres
• Excellent crush resistance
• Metallic armors providing good anti-rodent performance
• Applicable to duct and buried installations
Technical Characteristics
| Type | Units |
Cable diameter (mm) |
Cable weight (Kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static (mm) |
||
|---|---|---|---|---|---|---|---|---|
|
6 | 13.0 | 199 | 1500/3000 | 1000/3000 | 20D/10D | ||
| GYKTA53-38-72Xn | 6 | 15.0 | 244 | 1500/3000 | 1000/3000 | 20D/10D | ||
| GYKTA53-74-96Xn | 8 | 16.8 | 290 | 1500/3000 | 1000/3000 | 20D/10D | ||
| GYKTA53-98-120Xn | 10 | 17.8 | 333 | 1500/3000 | 1000/3000 | 20D/10D | ||
| GYKTA53-122-144Xn | 12 | 20.0 | 389 | 1500/3000 | 1000/3000 | 20D/10D |
Note:
1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.
2. For color arrangement of fibres and loose tubes, see the color sequence.
3. D is cable diameter.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available
