• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing key protection for fibres
• Excellent crush resistance and flexibility
• FRP armor providing good anti-bird and anti-rodent performance
• Small size and light weight, easy for installation
• Applicable to duct and aerial installations
Technical Characteristics
| Type |
Cable diameter (mm) |
Diameter of uni-tube (mm) |
Cable weight (Kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term （N/100mm |
Bending radius Dynamic/static (mm) |
|---|---|---|---|---|---|---|
| GYKFXTY-02-12Xn | 7.6 | 2.4 | 49 | 600/1500 | 1000/2000 | 25D/12.5D |
| GYKFXTY-14-24Xn | 8.2 | 3.0 | 64 | 600/1500 | 1000/2000 | 25D/12.5D |
| GYKFXTY-26-36Xn | 8.8 | 3.6 | 75 | 600/1500 | 1000/2000 | 25D/12.5D |
| GYKFXTY-38-48Xn | 9.2 | 4.0 | 81 | 600/1500 | 1000/2000 | 25D/12.5D |
Note:
1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.
2. For color arrangement of fibres, see the color sequence.
3. D is cable diameter.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available
