• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing key protection for fibres
• Excellent crush resistance
• Metallic armors providing good anti-rodent performance
• Nylon outer sheath with high hardness providing certain anti-termite performance
• Applicable to duct and buried installations
Technical Characteristics
| Type | Units |
Cable diameter (mm) |
Cable weight (Kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static (mm) |
||
|---|---|---|---|---|---|---|---|---|
| GYFTA54-24Xn | 6 | 14.4 | 225 | 900/2700 | 1000/3000 | 20D/10D | ||
|
6 | 15.0 | 250 | 900/2700 | 1000/3000 | 20D/10D | ||
| GYFTA54-72Xn | 6 | 15.0 | 250 | 900/2700 | 1000/3000 | 20D/10D | ||
| GYFTA54-96Xn | 8 | 16.8 | 300 | 900/2700 | 1000/3000 | 20D/10D | ||
| GYFTA54-144Xn | 12 | 20.0 | 370 | 900/2700 | 1000/3000 | 20D/10D | ||
| GYFTA54-288Xn | 24 | 22.4 | 465 | 900/2700 | 1000/3000 | 20D/10D |
Note:
1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.
2. For color arrangement of fibres and loose tubes, see the color sequence.
3. D is cable diameter.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available
