• All-dry design improving efficiency of construction and splicing
• Good structure design and accurate process control ensuring good mechanical and temperature performances
• Easy for self-supporting aerial installation, reducing installation costs
• Excellent crush resistance
Technical Characteristics
| Fibre count |
Tube diameter （mm） |
Tubes |
Diameter of strength member （mm） |
Diameter of coated strength member （mm） |
Diameter of cable core （mm） |
Fillers |
|---|---|---|---|---|---|---|
| 06-12Xn | 2.4 | 1 | 2.25 | - | 12.5 | 4 |
| 24Xn | 2.4 | 2 | 2.25 | - | 12.5 | 3 |
| 36Xn | 2.4 | 3 | 2.25 | - | 12.5 | 2 |
| 48Xn | 2.4 | 4 | 2.25 | - | 12.5 | 1 |
| 72Xn | 2.4 | 6 | 2.6 | - | 13.0 | 0 |
| 96Xn | 2.4 | 8 | 3.5 | 4.2 | 14.5 | 0 |
| 120Xn | 2.4 | 10 | 3.5 | 5.6 | 16.3 | 0 |
| 144Xn | 2.4 | 12 | 3.5 | 7.2 | 17.5 | 0 |
| 288Xn | 2.4 | 24 | 3.5 | 4.8 | 20.0 | 0 |
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available.
