• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing the key protection for fibres
• Excellent crush resistance and flexibility
• Small size and light weight, easy for installation
• Steel wire and steel tape armors providing excellent anti-rodent performance
• Applicable to duct, aerial and buried installations
Technical Characteristics
|
Type (in 2F increments) |
Fibre count |
Tube size （mm) |
Nominal thickness of sheath （mm） |
Cable diameter （mm） |
Cable weight （kg/km） |
Tensile strength Long/short term （N） |
Crush Long/short term （N/100mm） |
|---|---|---|---|---|---|---|---|
| GYXTY53-2-12 Xn | 2-12 | 2.5 | 2.0 | 10.9 | 144 | 600/1500 | 1000/3000 |
| GYXTY53-14-18Xn | 14-18 | 2.8 | 2.0 | 11.2 | 155 | 1000/3000 | 1000/3000 |
| GYXTY53-20-24Xn | 20-24 | 3.2 | 2.0 | 11.6 | 167 | 1000/3000 | 1000/3000 |
| GYXTY53-26-30Xn | 26-30 | 3.5 | 2.0 | 11.9 | 178 | 1000/3000 | 1000/3000 |
| GYXTY53-32-36Xn | 32-36 | 3.8 | 2.0 | 12.2 | 186 | 1000/3000 | 1000/3000 |
Note:
1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.
2. For color arrangement of fibres, see the color sequence.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 4,000m; other lengths are also available.
