JIANYE Roader® Micro-trench Optical Cable (GLFXTS)

Features

• Accurate process control ensuring good mechanical and temperature performances
• The material of loose tubes with good hydrolysis resistance and relatively high strength
• Tube filling compound providing the key protection for fibres
• Excellent crush resistance and flexibility
• Water resistance of optical cable is ensured by the following measures:
• Special water blocking compound filled in loose tubes
• Laminated steel tape armor
• Cable filling compound ensuring longitudinal water resistance



Type	Fibre count	Tube diameter （mm）	Cable diameter （mm）	Cable weight （Kg/km）	Crush Long/short term （N/100mm）	Tensile strength Long/short term（N）	Bending radius Dynamic/static（mm）
GLFXTS-02-12Xn	2-12	3.0	8.5	70	300/1000	300/1000	20D/10D

Note:

1. Xn refers to fibre type. For details, see naming rules for optical cables of JIANYE.

2. For color arrangement of fibres and loose tubes, see the color sequence.

3. D is cable diameter


Environmental Characteristic

• Transport/storage temperature: -40℃ to +70℃

Delivery Length

• Standard length: 4,000m; other lengths are also available.
