JIANYE GYXTW Optical Cable 2 To 48 Cores HDPE Jacket with Steel messger wire
JIANYE GYXTW Optical Cable 2 To 48 Cores HDPE Jacket with Steel messger wire

JIANYE GYXTW Optical Cable 2 To 48 Cores HDPE Jacket with Steel messger wire

Item No.: 015
INQUIRY
Description
Description

JIANYE Communication cable manufacturer that fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.

Features
⚫ Good mechanical and temperature performance
⚫ High strength loose tube that is hydrolysis resistant
⚫ Special tube filling compound ensure a critical protection of fiber
⚫ Crush resistance and flexibility
⚫ Two parallel steel wires ensure tensile strength
⚫ Small diameter, light weight and friendly installation

Application
⚫ Suitable for ducts & aerial fiber optic cable
⚫ Local area network system
⚫ Long distance communication system
⚫ Subsriber network

construction details
Items  Description
Number of fiber 2-24 cores(G652.D)
Tube number  1
Moisture Barrier  Water blocking system
Steel wire Number 2
diameter 0.8 mm
Loose tube material  PBT
diameter  Ф2.2mm(outer/inner)
Tube-filling material  Tube filling compound
Outer sheath material  HDPE,LSZH( can be required)
color  Black (can be required)
Cable diameter 2 cores to 24 cores  8.0±0.3mm
Weight 65±10kg/km
Installation Temperature range -15--+60℃
Operation and transport temperature  -40-+70℃
Min Bending Radius(mm) Long term 10D
short term 20D
Allowable Tensile Strength(N) Long term 600
short term 1500
Crush Load (N/100mm) Long term 300
short term 1000
Our advantages
(1) Professional cable manufacturer
(2) About 15 years experiences in cable industry
(3) MOQ just 1Km
(4) ISO, UL , ROSH,REACH...certifications
(5) Can be customized production of fiber optic cable.

Fiber Optic Cable Mechanical Performance Testing Laboratory
(1) Main Testing Type: Precision Test and Mechanical Test.
(2) Precision Testing Machine: EXFO OTDR, EG&G PMD-440,CD-400.
(3) Mechanical Performance Testing : Temperature, Impact, Tensile, Bending, Torsion,
(4) Flexing, Winding, Vibration, Water Penetration, Fusion Splicer, Water Penetration.

Cable marking and cable reel marking
1.Cable marking
The cable sheath shall be marked with white characters at intervals of one meter with
following information:
(1) Purchaser’s name
(2) Cable type
(3) Fiber type and counts
(4) Year of manufacture
(5) Length marking
Notice: cable mark is available if requested by customer.
2 Cable reel
Details given below shall be marked with a weather materials on both outer sides of the
reel flange :
(1) Cable type and fiber counts
(2) Length of cable in meters
(3) Year of manufacture
Notice: shipping mark is available if requested by customer.
3 Packing Informations
(1) Packing material: Wooden drum
(2) Cable end protect material: waterproof-cap
(3) Packing length: standard length of cable shall be 4km. Other cable length is also
available if required by customer
Requirement for Order
(1) Fiber sort: Single mode:G652,G655,G657, Multi mode:OM1,OsM2,OM3,OM4.
(2) Fiber brand: YOFC, Corning, Fiberhome,Fujikura,OFS etc.
(3) The fiber and tube color: according to stranded color, can be required.
(4) The cable Size: shall be in accordance with the table, can be required.
(5) Length of cable: generally is 4KM, can be required.
(6) Other requirement: can be negotiated.
