• Good mechanical and temperature performances
• All-dielectric design, applicable to lightning-prone areas
• Aramid yarns ensuring tensile strength of optical cable
• Small size and light weight, easy for installation
• Different tensile strength can be designed on request for short-distance self-supporting aerial and duct installations
Technical Characteristics
| Type |
Cable diameter (mm) |
Diameter of uni-tube (mm) |
Cable weight (Kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term （N/100mm） |
Bending radius Dynamic/static (mm) |
|---|---|---|---|---|---|---|
| GYAXZY-02~12Xn | 6.0 | 3.0 | 42 | 600/1500 | 300/1000 | 20D/10D |
• In the distribution segment of optical cable networks in rural areas, the cable can be used as drop cables for self-supporting aerial installation to connect branching points with access points for subscribers.
• Transport/storage temperature: -40℃ to +70℃
• Standard length: 2,000m; other lengths are also available.
